Feature

· Complies with IEEE802.3 and IEEE802.3u 10/100Base-TX and 100Base-FX
· MTU size supported 1600 bytes maximum
· Supports pure converter mode data forwarding for extreme low latency
· Built in 128Kb RAM for data buffer
· Supports modified cut-through frame forwarding for low latency
· Optional forward fragments
· 10/100Mbps and full/half duplex automatically configure in TP port
· Supports end fault function (optional)

· MDI/MDI-X Auto Negotiation
· Support EEPROM configuration
· LED Indicators: POWER, FX LINK/ACT, 100, TP LINK/ACT, FDX/COL.
· FCC Class A & CE approved
· LLR, LFP - Link Loss Return (LLR), Link Failure Pass (LFP) features supported
· RoHs compliant
· Only 1 fiber used instead of 2 - WDM BiDi technology
· Stainless steel parts (value added feature)
· Standalone, Wallmount or Hotpluggable in 19' chassis - universal design

Application

Expands the Size of an Existing Network
Provides fiber connectivity to Ethernet segments, allowing for even further networking expansion between extended workgroups. Also provides building-to-building connectivity without the need for the cost and disruption associated with the installation of additional routers.
Enhances the Distance between Networking Devices
Connecting the converter to fiber segments can further extend distances between networking nodes. This can be achieved by direct connection between the converter anda fiber-based node or networking device.

Wavelength: 1310nm for 10Km
Technical:
BER: <1E-8
Data Buffer: 128Kb
Power temperature variation: 0．2mw/℃
Input Power Range (dBm): 0~-40
Imax: 800mA
Power: 2.5 W
Fiber cable(m): 8.3/125, 8.7/125, 9/125 or 10/125single-mode
Maximum distance: 120 km (available ordering options 20/40/60/80/100/120 km)
Input power: IA@+5VDC or 110~260VAC or 48VDC
Environment:
Relative humidity;5% to 90%
Operating temperature: 0 to 70 degrees
Storage temperature : -20 to 70
